ONLINE HIGH RANGE TURBIDITY ANALYZER

Dual-Beam Infrared Scattered Light Photometer Detection:for accurate and stable measurements
Built-in Self-Diagnosis Function:Ensures data accuracy and reliability
Plug-and-Play Sensors:Quick and easy installation for user convenience
Optional Automatic Cleaning Function:Reduces sensor maintenance and enhances usability

Specifications	Details
MODEL	ZY-CON-TURB-H
MAIN MATERIAL	Body:PVC
MEASUREMENT RANGE	0.01-100 NTU
ACCURACY	Less than ±2% of the measured reading or ±0.1 NTU
RESOLUTION	0.01~0.1NTU, base on range
REPEATABILITY	±2%
TEMPERATURE RANGE	0-80°C (Non-freezing)
PRESSURE RANGE	4 Bar
CABLE LENGTH	Standard: 3m
OUTPUT	Digital RS485 Modbus
